RANGES
From DeWitt Refrigeration and Royal
|
|
|
|
Range 24" |
Range 36" |
Range 48" |
|
|
|
|
Raised Griddle 60" |
Range 72" |
Range-Radiant Broiler 36" |
Open Top Burners:26,000 BTU/hr, cast iron burner with venturi. Standing pilot for each burner. 12" x 24" heavy duty cast iron top grates. Full
width crumb/drip tray removable. Chrome plated cast metal knobs.
Griddle: 3/4" thick highly polished plate. 20,000 BTU/hr burner for every 12" of griddle surface. Griddle located on the left side of range standard. Manual control gas valves are standard.
Thermostatic control and 1" thick plate available as option with upcharge.
Oven: Solid welded front frame. Stainless steel lift off door. Porcelain finish on sides, door, and bottom. 35,000 BRU/hr steel burner. One chrome plated rack, two rack positions. Adjustable
thermostat control: 150 F to 500 F (66 C to 260 C). 100% safety pilot with matchless, push button ignition. Dimensions: 26-1/2" wide x 22-1/2" deep x 14" high.
Size: Overall depth of 30" including flue/back guard. Cooking height (with legs or optional casters) is 36". Overall height with flue/back guard is 56". Model # code –
RR-4G36 4= number of burners G36= 36” flat grill.
Back
SPECIFICATIONS |
||||||||||||||
|
24" Wide Range Series |
|
36" Wide Range Series |
||||||||||||
|
Model |
Width |
Depth |
Height |
B.T.U. |
Weight |
Price |
|
Model |
Width |
Depth |
Height |
B.T.U. |
Weight |
Price |
|
RR-4 |
24" |
30" |
36" |
131,000 |
400 lbs |
ASK |
|
RR-6 |
36" |
30" |
36" |
191,000 |
600 lbs |
ASK |
|
RR-2G12 |
24" |
30" |
36" |
99,000 |
420 lbs |
ASK |
|
RR-4G12 |
36" |
30" |
36" |
159,000 |
620 lbs |
ASK |
|
RR-G24 |
24" |
30" |
36" |
67,000 |
440 lbs |
ASK |
|
RR-2G24 |
36" |
30" |
36" |
127,000 |
630 lbs |
ASK |
|
|
|
|
|
|
|
|
|
RR-G36 |
36" |
30" |
36" |
95,000 |
650 lbs |
ASK |
|
48" Wide Range Series |
|
60" Wide Range Series |
||||||||||||
|
Model |
Width |
Depth |
Height |
B.T.U. |
Weight |
Price |
|
Model |
Width |
Depth |
Height |
B.T.U. |
Weight |
Price |
|
RR-8 |
48" |
30" |
36" |
243,000 |
800 lbs |
ASK |
|
RR-10 |
60" |
30" |
36" |
330,000 |
1,005 lbs |
ASK |
|
RR-6G12 |
48" |
30" |
36" |
211,000 |
820 lbs |
ASK |
|
RR-6G24 |
60" |
30" |
36" |
266,000 |
1.085 lbs |
ASK |
|
RR-4G24 |
48" |
30" |
36" |
179,000 |
830 lbs |
ASK |
|
RR-4G36 |
60" |
30" |
36" |
234,000 |
1,110 lbs |
ASK |
|
RR-2G36 |
48" |
30" |
36" |
147,000 |
850 lbs |
ASK |
|
RR-2G48 |
60" |
30" |
36" |
202,000 |
1,120 lbs |
ASK |
|
RR-G48 |
48" |
30" |
36" |
115,000 |
870 lbs |
ASK |
|
RR-G60 |
60" |
30" |
36" |
170,000 |
1,140 lbs |
ASK |
|
72" Wide Range Series |
|
Radiant Range Series |
||||||||||||
|
Model |
Width |
Depth |
Height |
B.T.U. |
Weight |
Price |
|
Model |
Width |
Depth |
Height |
B.T.U. |
Weight |
Price |
|
RR-12 |
72" |
30" |
36" |
396,000 |
1,206 lbs |
ASK |
|
RBR-24 |
24" |
30" |
36" |
87,000 |
515 lbs |
ASK |
|
RR-10G12 |
72" |
30" |
36" |
286,000 |
1,030 lbs |
ASK |
|
RBR-36 |
36" |
30" |
36" |
125,000 |
635 lbs |
ASK |
|
RR-8G24 |
72" |
30" |
36" |
286,000 |
1,230 lbs |
ASK |
|
RBR-48 |
48" |
30" |
36" |
174,000 |
825 lbs |
ASK |
|
RR-6G36 |
72" |
30" |
36" |
286,000 |
1,230 lbs |
ASK |
|
|
|
|
|
|
|
|
|
RR-4G48 |
72" |
30" |
36" |
254,000 |
1,255 lbs |
ASK |
|
|
|
|
|
|
|
|
|
RR-2G60 |
72" |
30" |
36" |
221,000 |
1,280 lbs |
ASK |
|
|
|
|
|
|
|
|
